MR-J4-700A Mitsubishi Servo Amplifier Mitsubishi MR-J4 Series 7KW Servo Diver 100% Original adn New

MR-J4-700A Mitsubishi Servo Amplifier Mitsubishi MR-J4 Series 7KW Servo Diver 100% Original adn New
Warehouse in stock

• MR-J4-700A

• Manufacturer: Mitsubishi Electric

• Series name: MELSERVO-J4 series

• Command interface: General-purpose interface

• Voltage class: 200V

• Motor rated output [KW]: Seven

• Servo amplifier Model: MR-J4-700A-RJ

• output: Rated voltage: Three-phase AC170 V

• Rated current: 37.0 [A]

• Main circuit power input:Voltage and frequency (Note 1): Three-phase AC200 V ~ 240 V, 50 Hz / 60 Hz

• Parameter setting or set by external analog input (DC0 V ~ ± 10 V / rated speed)

• Point table method, program type, equally divided indexing method (Note 17)

• 2-wire / 4-wire communication system

• Mitsubishi high-speed serial communication / ABZ phase differential input signal

• Advanced vibration suppression control Ⅱ, adaptive filter Ⅱ, robust filter, auto-tuning, one-touch adjustment, tough drive function, drive recorder function, machine

• diagnostics, power monitor function, super trace control (Note 15), lost motion correction function (Note 15 )

• Overcurrent cut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal), servo motor overheat protection, encoder error protection, regenerative

• error protection, undervoltage protection, instantaneous power failure protection, overspeed protection, excessive error protection, magnetic pole detection and

• protection, linear servo control error protection

• Safety function: STO (IEC / EN 61800-5-2)

• Overseas Compliance: The correspondence to the international standards and laws, Standards Compliant page please refer to.

• Environmental condition: Ambient temperature: Operation: 0 ° C ~ 55 ° C (non-freezing), storage: -20 ° C ~ 65 ° C (non-freezing)

• Ambient humidity: Operation / save: 90% RH or less (non-condensing)

• atmosphere: Indoors (no direct sunlight), that there is no corrosive gas, flammable gas, oil mist, dust and dirt

• elevation: 2000 m above sea level or less (Note 18)

• Vibration resistance: 5.9 M / s 2 , 10 Hz ~ 55 Hz (X, Y, Z each direction)

• Shipping Weight: 7.2 Kg

MR-J4 Series Model List:

Shenzhen Hunt Electronics Co., Ltd.Always be here offer you the best price and good after-sales services.

Our advantage range:
1. Mitsubishi A,Q,L, FX-series PLC;
2. Mitsubishi Frequency Inverter FR-A700, FR-E700, FR-F700, FR-D700-series.
3. Mitsubishi HMI(Human Machine Interface) GT16, GT15, GT12, GT10,GT20-series
4. Mitsubishi servo drive J4, J3, J2S,JE series

FAQ:
1. Q: Does all products are original?
Yes, we dealed are all brand new and original products.
2. Q: How about the warranty?
We supply 1 year warranty
3. Q: What about delivery time?
Normally 1-3days
4. Q: How about the payment term?
T/T, Western union are welcome
